SPECIALIZED

S-Works Turbo Levo R

SKU:95226-0104

R 285,000.00

~~R 160,000.00~~ R 285,000.00

Sale Sold out

Taxes included.

Color Gloss Premium Fjord Metallic / White Gloss Shadow Silver Blended Speckle Over Carbon / Silver Dust

Size S2 S3 S4 S5 S6

Quantity

CLICK HERE TO VIEW PICK UP IN STORE AVAILABILITY

Bell's Cycling

Shop1 A Riverside Junction, R40,Riverside, Nelspruit, 1200

Trading Hours: Mon - Fri: 08:00am to 17:00pm | Sat: 09:00am to 14:00pm | Sun: Closed

SuperNatural Power, Agility, and Range

Levo R

Nothing this powerful has ever felt this agile. Light, tight, and ready to fight, Levo R channels the SuperNatural power of Levo 4 but sheds its manners. Like a rally car unleashed on dirt, you and Levo R become one, stealing endless flow and finishing with the grin of a thief who slipped away clean.<br>This is Electric Rally.

At a Glance

Use

Full Power Electric Rally

E-System

S-Works 3.1 Motor w/ 850 Watts & 111 Nm, 840 Wh battery, up to 4.40 hour range w/ optional Range Extender

Frame

FACT 11m Carbon w/ Carbon Link, Geo Adj & SWAT Storage

Suspension

Front: 140mm FOX 36 SL FACTORY GRIP X<br>Rear: 130mm GENIE - FOX FLOAT Factory

Drivetrain

SRAM XX Transmission

Wheels

Traverse SL2 w/ Hydra2 Hubs

View full details

Technical Specifications

E-Bike

Battery

840Wh battery

UI/Remote

Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My

Charger

Specialized 12amp smart charger, 4 different charge functions including Standard, Fast, Eco, and charge to 80%

Motor

Specialized 3.1 S-Works motor, 111Nm power, 720W power

Frameset

Seat Binder

Alloy, 38.6mm

Frame

FACT 11m Carbon, carbon shock extension, titanium hardware, SWAT downtube storage, 12x148mm UDH compatible rear dropout, side entry battery, adjustable geometry, 130mm of travel

Suspension

Fork

FOX 36 SL Factory, GRIP X Damper, HSC, LSC, LSR adjust, 140mm travel, 44mm offset, 15x110mm

Rear Shock

FOX FLOAT Factory GENIE, Ride Dynamics Developed, 2-position compression adjust, 190x45mm

Brakes

Front Brake

SRAM Motive Ultimate, 4-piston caliper, hydraulic disc, 200mm rotor

Rear Brake

SRAM Motive Ultimate, 4-piston caliper, hydraulic disc, 200mm rotor

Drivetrain

Chainrings

SRAM 34t T-Type chainring, 104 BCD, steel

Shift Levers

SRAM AXS POD Ultimate Controller

Crankset

SRAM XX Carbon crank, 160mm, ISIS interface

Rear Derailleur

SRAM XX Eagle AXS

Cassette

SRAM XX Transmission, XS 1297, 10-52t

Chain

SRAM XX, T-TYPE

Wheels & Tires

Rear Wheel

Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra 2 Hub, 12x148mm, 32H, DT Swiss Revolite Spokes, 6 bolt

Front Wheel

Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 Hydra 2 Hub, 15x110mm, 28H, DT Swiss Revolite Spokes, 6 bolt

Front Tire

Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4

Rear Tire

Specialized Purgatory, GRID Trail Casing, T9 Compound, 29x2.4

Inner Tubes

Specialized Turbo Tube

Cockpit

Grips

Deity Lockjaw Grips

SeatPost

RockShox Reverb AXS, 34.9mm, S2: 125mm, S3: 150mm, S4-6: 200mm

Handlebars

Roval Control SL RISE Integrated cockpit, 50mm integrated stem, 8-degree backsweep, 2 degree upsweep, 780mm wide

Saddle

Specialized S-Works Power Mirror, Ti Rails, 143mm/155mm

Accessories

SWAT

SWAT internal downtube storage

Product Details

Product ID

223520

Compliance Certification

As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. <br>For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)

Weight

21.16 kg (46 lb, 10.4 oz)

Weight Size

Geometry

	S1 - 27.5	S2 - 29	S3 - 29	S4 - 29	S5 - 29	S6 - 29
Crank Length	160	160	160	160	160	160
Handlebar Width	800	800	800	800	800	800
Stem Length	50	50	50	50	50	50
Saddle Width	155	155	143	143	143	143
Seatpost Length	125	125	150	170	190	190
Stack	602	607	616	630	644	657
Reach	400	420	450	475	500	525
Head-Tube Length	95	100	110	125	140	155
Head-Tube Angle	64.8	65	65	65	65	65
B-B Height (low)	339	339	339	339	339	339
B-B Drop	36	36	36	36	36	36
Trail	128	126	126	126	126	126
Fork Length (full)	550	550	550	550	550	550
Fork Rake/Offset	44	44	44	44	44	44
Front Center	716	736	770	801	833	863
Chain-Stay length	447	447	447	447	447	447
Wheelbase	1160	1181	1215	1246	1277	1309
Top-Tube Length (horizontal)	539	560	592	620	649	677
Bike Stand-Over Height	761	763	773	783	793	803
Seat-Tube Length	375	385	405	425	445	465
Seat-Tube Angle	77	77	77	77	77	77
Seat Post Max Insertion	292	312	210	227	249	271
Seat Post Min Insertion	80	80	80	80	80	80
Saddle Height for Effective ST Angle	645	690	735	780	825	870

Size Guide

Size Chart

Height (Cm)	Size
150-160	S1
157-173	S2
165-180	S3
173-188	S4
178-193	S5
188-203	S6

Height (In)	Size
59-63	S1
62-68	S2
65-71	S3
68-74	S4
70-76	S5
74-80	S6
